Magtek Mini-MICR

**Ingenico iCT**: The CAB350086A cable adapter is also required.
**PAX 80**: The 1000001866-A cable adapter is also required.
**VeriFone Omni Vx520**: The 08798-01-R USB-RS232 Adapter will be required if PIN Pad is connected to the RS232 port.
Terminal Type	Connector Description	Part Number
Dejavoo C-Series, M-Series and X-Series	RS-232 (Reader Connection) and RS (RJ-11, Terminal Connection), the cable is currently available through TASQ or The Phoenix Group.	CC-CR0327 —— —— —— —— E-106583
Dejavoo V-Series and Z-Series	RS-232 (Reader Connection) and COM2 (RJ-45, Terminal Connection), the cable maybe Gray in color and 6 feet long.	315600414000
Hypercom T4100	RS-232 (Reader Connection) and RS-232 (9-Pin Mini-DIN, Terminal Connection), the cable is Gray in color and 9 feet long.	22517577 REV A
Hypercom T4200	RS-232 (Reader Connection) and SERIAL (RJ-11, Terminal Connection), the cable is Gray in color and 9 feet long.	22517588 REV A
Hypercom T7 Series Using FIP-11 Interface	RS-232 (Reader Connection) and COM2 (RS-232 DB-9 Female FIP Interface Connection), the cable is Gray in color and 9 feet long.	22517563 REV A
Hypercom T7 Series Using FIP-11 Interface	RS-232 (Reader Connection) and COM2 (RS-232 DB-9 Female FIP Interface Connection), the cable is Black in color and 9 feet long.	22517579 REV B
Hypercom T7 Series	RS-232 (Reader Connection) and RS-232 (9-Pin Mini-DIN, Terminal Connection), the cable is Gray in color and 9 feet long.	22517577 REV A
Ingenico i-Series	RS-232 (Reader Connection) and RS-232-2 (RJ-11, Terminal Connection), the cable is Gray in color and 2 feet long.	22517517 REV A
Ingenico iCT Series	RS-232 (Reader Connection) and RS-232-2 (RJ-11, Terminal Connection), the cable is Gray in color and 2 feet long.	22517517 REV A (See Note Below)
Nurit (all models)	RS-232 (Reader Connection) and COM1/RS-232 (RJ-45, Terminal Connection), the cable is Gray in color and 9 feet long.	22517559 REV A —— —— —— —— 22517580 REV A
PAX80	RS-232 (Reader Connection) and COM (RS-232 DB-9 Female Connection), the cable is Gray in color and 9 feet long.	22517563 REV A (See Note Below)
PC Charge Pro	RS-232 (Reader Connection) and PS2 Keyboard (Computer Connection), the cable is Gray in color and 9 feet long. For Check Reader with P/N 22530005.	22517501 Rev B
PC Desktop Terminal	RS-232 (Reader Connection) and USB (Any USB Computer Connection), the cable is Gray in color and 6 feet long.	22517583 REV B
PC Virtual Terminal		22517583 REV B
TechTrex PrimeTrex	RS-232 (Reader Connection) and PIN† (RJ-14, Terminal Connection), the cable is Gray in color and 6 feet long.
Thales Talento	RS-232 (Reader Connection) and INTERFACE (DB-9 Male, Interface Connection), the cable is Gray in color and 9 feet long.	22517574 REV A
VeriFone Omni (all models)	RS-232 (Reader Connection) and RS-232 (RJ-45, Terminal Connection), the cable is Gray in color and 9 feet long.	22517559 REV A —— —— —— —— 22517580 REV A (See Note Below)


	The part numbers listed below are not the only cables available to the merchants, these numbers were gathered from TASQ Technologies, JR’s POS Depot, The Phoenix Group, and a few others. Note: The cable for the VeriFone CR-600 Reader will connect to this reader, but it will not work.
