The EC9100i® series check scanners are affordable, compact, and efficient. The multifunctional capabilities of the scanners enable your business to capture and process any combination of payment types including: checks, remittances, payment cards, loyalty cards and ID cards. They also offer check defacement, endorsement and receipt printing capabilities – all on a single device.

The EC9100i series check scanners deliver industry leading MICR read rates and superior image quality which surpass industry requirements. With multiple models to choose from, one small multifunctional device can capture checks, remittances, payment cards, ID cards or print receipts.

Available in both single-feed (SF) and auto-feed (AF) models, the EC9100i scanners are designed to fit your workflow volumes and are priced to fit your budget. The AF series models enable batch scanning at speeds up to 30 or 90 documents per minute (dpm).


EC-9100i AF Series
Model Part Number Description
30 Documents Per Minute (DPM)
EC-9103f AF30X 6000-9103-3000  Auto-feed with endorser.
EC-9103f AF30X 6000-9103-3010  Extended auto-feed with endorser.
EC-9103f AF30X 6000-9103-300R  Auto-feed with endorser and OCR licensed.
EC-9103f AF30X 6000-9103-301R  Extended auto-feed with endorser and OCR licensed.
EC-9104f AF30X 6000-9104-3000  Auto-feed with endorser and MSR.
EC-9104f AF30X 6000-9104-3010  Extended auto-feed with endorser and MSR.
EC-9104f AF30X 6000-9104-300R  Auto-feed with MSR, endorser and OCR licensed.
EC-9104f AF30X 6000-9104-301R  Extended auto-feed with MSR, endorser and OCR licensed.
EC-9107f AF30X 6000-9107-3010  Extended auto-feed with endorser and receipt printer.
EC-9107f AF30X 6000-9107-301R  Extended auto-feed with endorser, receipt printer and OCR licensed.
EC-9108f AF30X 6000-9108-3010  Extended auto-feed with MSR, endorser and receipt printer.
EC-9108f AF30X 6000-9108-301R  Extended auto-feed with MSR, endorser, receipt printer and OCR licensed.
90 Documents Per Minute (DPM)
EC-9103f AF90X 6000-9103-9000  Auto-feed with endorser.
EC-9103f AF90X 6000-9103-9010  Extended auto-feed with endorser.
EC-9103f AF90X 6000-9103-900R  Auto-feed with endorser and OCR licensed.
EC-9103f AF90X 6000-9103-901R  Extended auto-feed with endorser and OCR licensed.
EC-9104f AF90X 6000-9104-9000  Auto-feed with MSR and endorser.
EC-9104f AF90X 6000-9104-9010  Extended auto-feed with MSR and endorser.
EC-9104f AF90X 6000-9104-900R  Auto-feed with MSR, endorser and OCR licensed.
EC-9104f AF90X 6000-9104-901R  Extended auto-feed with MSR, endorser and OCR licensed.
EC-9107f AF90X 6000-9107-9010  Extended auto-feed with endorser and receipt printer.
EC-9107f AF90X 6000-9107-901R  Extended auto-feed with endorser, receipt printer and OCR licensed.
EC-9108f AF90X 6000-9108-9010  Extended auto-feed with endorser, MSR and receipt printer.
EC-9108f AF90X 6000-9108-901R  Extended auto-feed with endorser, MSR, receipt printer and OCR licensed.

EC-9100i SF Series
Note: EC-9100i single-feed scanners cannot automatically pull documents into the scanner.
Model Part Number Description
EC-9111f SF 6000-9111-0000  Single-Feed.
EC-9111f SF 6000-9111-000R  Single-Feed and OCR licensed.
EC-9112f SF 6000-9112-0000  Single-Feed, MSR.
EC-9112f SF 6000-9112-000R  Single-Feed, MSR and OCR licensed.

More information on this unit can be found at www.rdmcorp.com.


Download RDM EC-9600i Data Sheet
Download RDM EC-9100i/9600i User Guide
Removal of FAP Cartridge Assembly





Updated: 08/11/2017
