| Terminal Displays
| Action Taken
|
HOME MENU
TSYS
Home
|
 |
 |
From the Home Menu, press the Red [Cancel] button.  |
Application
Manager
V 0.20
Please enter
system
Password:****** |
|
|
Key in 000000 and press the Green [OK/↵] button. |
TechTrex
AppManagerDownload
Remove
Enter
App
Set Main App |
|
|
Press the [F1] button. |
Download
Individual Download
Package download
|
|
|
Press the [F1] button to download TSYS or Gift Cards.
Press
the [F2] button to download Checks (Package). |
TechTrex
AppManagerAppl Download
Kernel Download
App Mngr Download
Logo Download |
|
|
Press the [F1] button. |
TechTrex
AppManagerSD Card
RS-232 Passive
IP Download
PSTN Full |
|
|
Press the [F3] button. |
Download
Network Setup?
YES NO |
|
|
Press the [Adjust] button to select Yes. |
IP Download
TMS IP
tms.techtrex.info
|
|
|
Confirm that "tms.techtrex.info" is displayed for the IP and press the Green [OK/↵]
button.
If incorrect, press the [A1] button and then the [9] button. Enter the correct URL and press the
Green [OK/↵] button. |
IP Download
TMS PORT
4002
|
|
|
Confirm that "4002" is displayed for the port and press the Green [OK/↵] button.
If incorrect, press the [A1] button and then the [9] button. Enter the correct URL and press the Green
[OK/↵] button. |
IP Connection
Dynamic
Static
Cancel |
|
|
Press the [F2] button to continuing the download via Dynamic.
Press the [F3] button
to continue setting the static settings. Click here to continue
to verify/edit the static settings.
Press the [F4] button to abort the download. |
Download
Please enter the
Reference #:
0 0
0 0 0 0 0 2 4 1 0 8 |
|
|
Enter the Reference Number for the merchant and press the Green [OK/↵] button. |
| Special Notes → |
CURRENT IDIVIDUAL REFERENCE NUMBERS:
TSYS: 000000019630 Gift Card: 000000019193
CURRENT PACKAGE REFERENCE NUMBERS:
Checks: 000000021408 |
| The packages will contain the latest versions of
the Kernal, Application Manger, Scanner Firmware, and the GETI Check application.
|
|
IP Download
Downloading
57% Completed
|
|
|
The terminal will connect and start downloading, this will also apparent by the
fact that the terminal will be beeping. |
IP Download
Download
Succeed
|
|
|
The download is done and now it will install the application. |
HOME MENU
TSYS
GETI
GETIGift
Home
|
|
|
The download is complete. |
